Passivation Solution

Passivation is a must after every pickling operation process.
Next apply K-2 passivation solution and leave it for 20-25 minutes.
Finally clean the surface thoroughly with water.


HOW TO APPLY K - 2 PASTE

1. First remove oil, dirt etc. with SI 56 degreaser. Add 50 - 75 gm/lit. in water & stir to dissolve. Wipe S.S. surface with cotton cloth or spray or soak for 10 min. Wash with water and allow to dry.
(Steps 1 & 5 can be avoided for K-2 PASTE on weld seam application )


2. K-2 PASTE is applied on weld seam & surrounding areas with a nylon bristled plastic brush OR
K-2 Spray is sprayed on S.S. surface with plastic pressurized spray bottle or pump
OR K-2 Dip is used to dip S.S. components in a plastic tank or circulated in pipeline with pump.
Application Temp. = Between 25 - 35 deg. C .
If temp. is less than more time may be required and if temp. is more than uneven processing may result. So, cool SS equipment by keeping its in shade & not directly under the sun.

3. Keep K-2 product for 10 - 45 minutes depending on contamination & scale. ( K-2 PASTE generally kept for 10 - 30 min. and K-2 Spray generally kept for 30 - 45 min. )

4. Wipe the weld seam lightly with plastic brush or cloth & wash with water thoroughly & allow to dry.
5. Spray or Dip in K-2 Passivation or K-2 Biopassive solution & leave it for 10- 20 minutes. Rinse with water thoroughly.


For Passivating Mirror Bright Buffed / Polished SS Areas,

THE BELOW STEPS WILL NOT AFFECT SHINE OF MIRROR BRIGHT BUFFED / POLISHED SS AREAS AND PROVIDE CONTAMINATION & STERILE PARTICLE FREE PASSIVATED SS SURFACE.
1 First apply K-2 PASTE on weld seam & surrounding areas with a nylon bristled plastic brush. After 10 to 30 min. wipe with cloth or plastic brush & wash with water thoroughly.
( Application of K-2 PASTE ensures that black & red spots do not come on & near weld seams area as generally observed some days after bright buffing. )


2 Complete usual bright buffing / polishing procedure to make surface mirror bright & shiny.
( If SS eqpt. or pipe is already bright buffed or polished then discard Steps 1 & 2 and start directly with Step 3 )

3 Remove oil, dirt, buffing compounds etc. with "SI 56" - sulphur free degreaser.
Add 50 - 75 gm/lit. in water ( 1 kg SI 56 in 15 – 20 Lit. water ) & stir to dissolve. Wipe S.S. surface with cotton cloth or pressurized spray for 2 - 5 min. or soak small parts for 10 min. Wash with water properly.

4 Spray or Dip in K-2 passivation or K-2 Biopassive & leave it for 15 - 25 minutes. Then, rinse with water thoroughly.

"SURFACE INNOVATORS " PROVIDES EQUIPMENTS & ACCESSORIES FOR SAFE, IN-HOUSE PICKLING & PASSIVATION FOR ALL TYPES OF JOBS.

PRODUCT APPROVED BY I.I.T. (BOMBAY) UNDER ASTM – A380
ASTM = American Standards of Testing Materials
